Key Features:

1. Front Accessible Service Switch (FASST)

   • Enables safe lamp replacement without electrical exposure

   • Meets OSHA safety requirements for maintenance personnel

   • Integrated mechanical disconnect mechanism

2. 2-Wire Installation

   • Simplifies retrofit applications

   • Compatible with existing wiring infrastructure

   • Reduces installation time by up to 40%

3. Interrupted Power Recovery

   • Automatic return to preset lighting levels after power restoration

   • Programmable memory function retains last settings

   • Eliminates need for manual reset after outages

4. Configurable Trimming

   • Adjustable high-end trim (100-50% output)

   • Adjustable low-end trim (50-1% output)

   • Field-configurable via DIP switches or software

5. 0-10V Control Interface

   • 60mA output capacity (source or sink)

   • Auto-configuring polarity detection

   • Compatible with most 0-10V dimming systems

   • 100% compatibility with LED/fluorescent/HID loads

Technical Specifications:

• Input Voltage: 120-277V AC, 50/60Hz

• Load Capacity: 20A maximum

• Control Signal: 0-10V DC

• Operating Temperature: -40°C to +60°C

• Enclosure Rating: NEMA 4X (indoor/outdoor)

• Compliance: UL 1472, FCC Part 15
