Core Specifications:

• Rating: 1200A, 208Y/120V AC, 3PH, 4-Wire

• Bus Capacity: 65 kAIC (silver-plated copper, 1000A/sq.in density)

• Main Breaker: 1200A, 3P with CT (1200:5 ratio)

• Outgoing Circuits:

  • (8) 225AF/200AT

  • (1) 225AF/100AT

• Metering: (3) 400A + (2) 200A + (1) 100A meter bases

Safety & Compliance:

✔ UL 891 Listed – Deadfront switchboard certified
✔ Service Entrance Rated – Meets utility requirements
✔ 24V Trip Unit – Ammeter display with GF protection (long/short/instantaneous/ground fault)
✔ Continuous Ground Bus – ¼" x 2" copper, solidly bonded

Enclosure Details:

• Material: #12-gauge HRPO steel (ANSI 61 gray epoxy coating)

• Type: Non-walk-in NEMA 1 (front-access, bottom cable entry)

• Dimensions: 216" W × 30" D × 90" H

• Weight: 8,500 lbs

Included Features:

• Thermostatically controlled space heaters

• Strip thermostat (65°C max rise)

• GFCI receptacles

• Rodent barrier

• (4) Form C aux contacts

• Terminal blocks & visual contact wear indicators
