QB Electrical
3P 800A -4W Fusible-Heavy Duty Safety Switch. 600VAC (800A).
Core Features
-
Type: 3-pole fused disconnect switch with solid neutral
-
Current Rating: 800A (higher capacity than HF365NA's 400A)
-
Voltage Rating: 600V AC
-
Fuse Configuration: 3-fuse assembly (accepts Class J, R, or T fuses)
-
Short Circuit Rating: Up to 200kA RMS symmetrical (when using Class R or J fuses)
-
Enclosure: NEMA Type 1 (indoor use only)
Construction & Safety
-
Enclosure Material: Heavy-duty steel
-
Mounting: Surface or panel mount
-
Handle: Standard with padlocking provisions (Lockout/Tagout compliant)
-
Contact Design: Visible blade for position confirmation
-
Interlock: Coin-proof, defeatable (prevents cover opening when ON)
SS-ID-600V-3P-800A-F-HF367N
- 1000 有存货
数量
QB Electrical
3P 800A -4W Fusible-Heavy Duty Safety Switch. 600VAC (800A).SS-ID-600V-3P-800A-F-HF367N
Core Features
-
Type: 3-pole fused disconnect switch with solid neutral
-
Current Rating: 800A (higher capacity than HF365NA's 400A)
-
Voltage Rating: 600V AC
-
Fuse Configuration: 3-fuse assembly (accepts Class J, R, or T fuses)
-
Short Circuit Rating: Up to 200kA RMS symmetrical (when using Class R or J fuses)
-
Enclosure: NEMA Type 1 (indoor use only)
Construction & Safety
-
Enclosure Material: Heavy-duty steel
-
Mounting: Surface or panel mount
-
Handle: Standard with padlocking provisions (Lockout/Tagout compliant)
-
Contact Design: Visible blade for position confirmation
-
Interlock: Coin-proof, defeatable (prevents cover opening when ON)
