L-Type 90° Track Lighting System Overview

1. Connector Type:

   • L-shaped connector (90° twist-lock) – common in L-type track systems (also called "L-track").

   • Distinct from H-type (J-track) or J-type (standard 1-circuit) systems.

2. Voltage & Wiring:

   • Typically 120V (single-circuit) in North America.

   • Ensure your fixture’s 120V input matches the track’s voltage.

3. Installation:

   • Step 1: Turn off power to the track.

   • Step 2: Align the fixture’s L-connector with the track’s slot and insert.

   • Step 3: Rotate the fixture 90° to lock into place (you’ll hear a click).

   • Step 4: Adjust the head for desired beam direction.

4. Compatibility Check:

   • Confirm your track is L-type (look for "L" or "LSC" markings).

   • If replacing an old fixture, match the connector shape (H/J/L).
