Electrical Ratings:

• Current Rating: 600 Amps (AC)

• Voltage Rating: 300V AC

• Interrupting Rating (AIC): 200,000 Amps RMS @ 300V AC (extremely high fault current protection)

Fuse Type & Performance:

• UL Class T (very fast-acting, current-limiting)

• Very Fast-Acting: Provides rapid response to overcurrent conditions

• Current Limiting: Prevents fault currents from reaching peak values, protecting downstream equipment

Physical Dimensions:

• Size: 1.25" (diameter) x 3.06" (length)

Certifications & Standards Compliance:

• UL Listed (Standard 248-15, Guide JDDZ, File E4273)

• CSA Certified (C22.2 No. 248.15, Class 1422-02, File 53787)

Typical Applications:

• High-current AC circuits requiring fast protection

• Industrial power distribution, UPS systems, battery banks, and renewable energy systems

• Situations requiring high interrupting capacity (200kA)

This fuse is designed for robust protection in demanding electrical environments where fast operation and high fault current interruption are critical.
