EKM Omnimeter I v.3 Advanced Energy Meter

3-Phase & Single-Phase | 120-480V | 5000A Capacity | Cloud-Enabled

Key Features

✔ Universal Electrical Compatibility

• 3-Phase (3-wire or 4-wire)

• Single-Phase (2-wire or 3-wire)

• 120V to 480V range

• 50/60Hz auto-detection

✔ High-Capacity Monitoring

• Measures up to 5000A via CTs

• ±0.5% accuracy

✔ Cloud Connectivity

• Free cloud data service with EKM Push3 gateway

• Real-time energy monitoring

• Historical data analysis

Technical Specifications

• Voltage Ranges: 120/208/240/277/480V

• Current Input: CT-based (external CTs required)

• Communication: RS-485 standard

• Enclosure: NEMA 4X rated

Included Features

• Energy (kWh) measurement

• Power (kW) monitoring

• Voltage/current/power factor

• Time-of-use tracking

Cloud Service Benefits

• Remote access via web/mobile

• Automated reports

• Multi-meter aggregation

• API for system integration
